F6/F9 MEDIUM SERIES HYDRAULIC ROCK BREAKERS – VERSATILITY AND POWER

These medium-sized rock breakers are engineered with a higher back head pressure and larger pistons for an increase in impact energy.

F6 and F9 rock breakers are available with FRD USA’s unique Switch Hitch side plate mounting system for backhoes and various excavator models. An indexing disc inserted in the side plate can be easily changed to accommodate quick couplers for many popular backhoes, including Case®, John Deere® and Caterpillar®. Attachment is as simple as rotating the disc to the OEM center dimension of the carrier then attach the hammer in the normal manner. There’s no need for separate OEM specific mounting brackets for each carrier. This design also increases tuck for better over the road transport and aids in loading and unloading of the equipment.

The F6/F9 Medium Series rock breaking hammers from Furukawa / FRD are available in a variety of mounting options for mini-excavators, skid-steer loaders & rubber-tired backhoes.

Improved Performance

  • Larger Pistons

  • Higher Back Head Pressure

  • Complete with our Exclusive Pro-Pak

The F6 and F9 also come in the popular Qt version to accommodate work environments that demand a reduced noise level. The F6 is available with a one-piece skid-steer loader bracket for large series skid-steer loaders. All FRD USA hammers come complete with our exclusive Pro-Pak for ease of installation. The Pro-Pak includes hose whips, mounting hardware, standard working steel and tool kit with operating manual at no additional charge.

Improved Performance

The F6 and F9 also come in the popular Qt version to accommodate work environments that demand a reduced noise level. The F6 is available with a one-piece skid-steer loader bracket for large series skid-steer loaders. All FRD USA hammers come complete with our exclusive Pro-Pak for ease of installation. The Pro-Pak includes hose whips, mounting hardware, standard working steel and tool kit with operating manual at no additional charge.

Features & Benefits

  • Increase in back head pressure and larger diameter piston results in greater impact energy.
  • Longer thrust bushing improves piston alignment during impact and incorporates grease holes to evenly distribute grease in the front head.
  • CD designed side bolt threads provide even load distribution and greater surface contact between the nut and the bolt reducing the chances of thru-bolt failure.
  • Increased front head wall thickness for added service life.
  • Nitrogen charged back head for superior energy transfer.
  • Large diameter piston for increased impact energy.
  • New front head design includes replaceable thrust bushing for added service life.
  • Includes two-year warranty with registration.
  • Increase in back head pressure and larger diameter piston results in greater impact energy.
  • Longer thrust bushing improves piston alignment during impact and incorporates grease holes to evenly distribute grease in the front head.
  • CD designed side bolt threads provide even load distribution and greater surface contact between the nut and the bolt reducing the chances of thru-bolt failure.
  • Increased front head wall thickness for added service life.
  • Large diameter piston for increased impact energy.
  • New front head design includes replaceable thrust bushing for added service life.
  • Includes two-year warranty with registration.
  • Nitrogen charged back head for superior energy transfer.

Specifications

Notes
1. Weights and lengths for all versions CARRIER OPTIONS include Working Steel
2. All weights and lengths for FSP’s and Qt versions marked**include a “Universal” Top Cap

F6/9 Series Cut-Away

CARRIER COMPATIBILITY GUIDE for MEDIUM HYDRAULIC BREAKERS

Select FRD Model

F6
F9

Choosing the Right Hydraulic Breaker

When operated properly, breakers efficiently and effectively break up concrete and shatter rock. If not operated properly or not sized correctly for the job, the attachment can fail unexpectedly and waste precious time on a job site, or even suffer a reduced lifespan.

GET THE GUIDE for the F6/F9 Medium Series rock breaking hammers from Furukawa / FRD

To learn more about proper operating techniques and choosing the right hydraulic breaker for your job, download our latest guide.
